Class D 4 Channel Amplifier
4x 100 watts RMS @ 2/4Ω
4ch High-Level input
Frequency Response: 10Hz-30000Hz
$15 Flat rate shipping*
We offer a $15 flat rate Australia-wide shipping service, no matter how many items, however large or heavy items may incur a higher freight charge. If your item/s is subject to additional freight charges due to being large or heavy, this will be calculated at checkout. If any damage occurs during shipping, it is the responsibility of the customer to notify us within 24 hours of the order arriving. This is a requirement of our freight insurance and we are unable to lodge any claims after 24 hours from delivery.
If you like to rev up your front and rear speakers, the M FOUR will be exactly the right "tool" to do so. With generously 100 Watts RMS per channel into both 4 Ohms and 2 Ohms load this amp will heat up your voice coils in no time despite its super-compact dimensions. On the other hand the M FOUR stays totally cool thanks to the highly efficient Class D design topology. 3-channel or 2-channel configurations are possible as well, delivering up to 2 x 200 Watts RMS of clean and undistorted output power.
Needless to say that the M FOUR is equipped with a bunch of intelligent attributes like "start-stop capability" and our proprietary "ADEP" highlevel input so that it easily deals with all installation challenges of modern cars. Finally the extensive audio features will offer a sound quality at its best.
Smart highlevel input
The latest generation of OE car radios incorporates sophisticated possibilities of diagnosing the connected speakers. If a common amplifier will be hooked up failure messages and loss of specific features (e.g. fader function) quite often appear - but not with the M FOUR. The new ADEP circuit (Advanced Diagnostics Error Protection) avoids all these problems without loading the speaker outputs of the OE radio during high volumes unnecessarily.
The switched power supply of the HELIX M FOUR assures operation even if the battery’s voltage drops down to 6 Volts during engine crank.
Small footprint Class D amplifier with high output power of 100 Watts RMS @ 4 and 2 Ohms load
Start-Stop capability down to 6V supply voltage
Smart highlevel input with ADEP circuit (Advanced Diagnostics Error Protection) and Auto Turn-On function
Integrated, active crossover with highpass, lowpass and bandpass
“Input mode” switch for flexible input signal routing
SMD (Surface Mounted Device) manufacturing technology combines minimum space requirement with maximum reliability
Exclusive, extremely compact and clean design with illuminated HELIX-logo and low heat dissipation thanks to extraordinary efficiency
Dimensions (H x W x D): 50 x 230 x 154 mm
Output power RMS / max.
- @ 4 Ohms
4 x 100 / 200 Watts
- @ 2 Ohms
4 x 100 / 200 Watts
- @ 1 Ohm
- bridged @ 4 Ohms
2 x 200 / 400 Watts
- bridged @ 2 Ohms
Max. output power per channel*
Up to 135 Watts RMS @ 4 / 2 Ohms
4 x RCA / Cinch 4 x Highlevel speaker input 1 x Remote In
