Description
xMille power amplifiers are born to fully enhance the outstanding performance of the Mille speakers. The new ADC (ADVANCED D-CLASS TECHNOLOGY) ensures pure listening pleasure while keeping a compact size with unmatched power efficiency.
The heat sink, engineered with double technology, extrusion and aluminium die-casting, enables the Mille Power amplifiers to work constantly at full power without ever overheating, further maximizing thermal efficiency. The powerful mono Hertz audio car amplifier ML Power 1 (1000 W – stable at 1 Ω) is perfect to drive the Mille subwoofers.
The filters combination adopted for the Mille Power line is extremely flexible and ensures they can be used in any configuration. The active crossovers of MLPower 1 feature a 24 dB/Oct. adjustable slope Lo-Pass filter to adapt to every need. The control section, protected by a removable panel, can be accessed from the top for an effortless tuning.
Specifications
|
GENERAL SPECS |
|
|
Channels |
1 |
|
Power supply voltage: |
11-15 VDC |
|
Idling current: |
2 A |
|
Idling current when off: |
0.04 mA |
|
Consumption @ 1Ω, 14.4 VDC |
83.5 A |
|
Distorsion - THD (100 Hz @ 4Ω): |
0.08 % |
|
Bandwidth (-3 dB): |
18 - 500 Hz |
|
S/N Ratio (A weighted @ 1 V) |
105 dB |
|
Damping factor (100 Hz @ 4Ω): |
100 |
|
Pre-In sensitivity: |
0.2 - 5 V RMS |
|
Pre-In impedance: |
15 kΩ |
|
Speaker-In sensitivity: |
0.8 - 20 V RMS |
|
Speaker-In impedance: |
470 Ω |
|
Load impedance: |
|
|
Remote In: |
4 - 15 VDC - 1 mA |
|
ART™: |
Automatic Remote Turn-On/Off with Speaker-In |
|
Fuse: |
3 x 40 A |
|
Max size (mm/inches): |
170 x 349 x 46.70 / 6.69 x 13.74 x 1.84 |
|
Weight (kg/lb): |
3.09 / 6.81 |
|
Adjustable Crossovers |
yes |
|
INPUTS / FILTERS |
|
|
Inputs: |
Pre IN / Speaker IN |
|
Outputs: |
Pre OUT |
|
Filters: Lo-pass |
50 - 500 Hz @ 24 dB/Oct |
|
Phase: |
(continuous adjustment) 0 ÷ 180° |
|
Subsonic: Hi-pass |
18 - 40 Hz @ 24 dB/Oct. |
|
Remote SUB Volume: |
(-50 - 6) dB |
|
OUTPUT/POWER |
|
|
CEA 2006-A RATINGS |
|
|
RMS Power (4 Ω, ≤ 1 % THD+N, 14.4 V): |
600 W x 1Ch |
|
S/N Ratio (ref. 1 W output): |
83,5 dBA |
|
OUTPUT POWER (RMS) @ 14.4 VDC, THD 1%: |
|
|
1 Ch |
600 W x 1 (4Ω) |
|
1 Ch |
1000 W x 1 (2Ω) |
|
1 Ch |
1000 W x 1 (1Ω) |
|
Total Power RMS |
1000 W |
For more information, please visit the manufacturer's website.
