Musway M16 16ch Amplifier with 24ch DSP
Musway M16 16ch Amplifier with 24ch DSP
Musway M16 16ch Amplifier with 24ch DSP
Musway M16 16ch Amplifier with 24ch DSP
Musway M16 16ch Amplifier with 24ch DSP
Musway M16 16ch Amplifier with 24ch DSP

Musway M16 16ch Amplifier with 24ch DSP

$3,200.00
$3,200.00
Brand: Musway
SKU: MUS M16
Availability: In Stock
16ch Class D Amplifier + 24ch DSP
12x 50w + 4x 120w @ 4Ω
12x 85w + 4x 215w @ 2Ω
Dimensions: 350 x 46 x 166mm

Purchase

If you are interested in buying this item please contact us via our contact page.

Contact Us
$15 Flat rate shipping*

Description
Description
x

Musway M16 16 Channel Amplifier with 24 Channel DSP

The MUSWAY M16 is a powerful 16-channel Class D amplifier featuring an integrated 24-channel DSP, designed to provide flexible, high-performance audio processing and amplification in modern vehicle sound systems. With MUSWAY’s Dynamic Headroom (DHR) technology, the M16 provides additional dynamic power reserves when different channels are not operating at full power simultaneously, helping deliver strong and controlled performance across the entire system.

The integrated DSP provides extensive tuning capabilities, including selectable crossover types, adjustable slopes, a 31-band parametric equalizer, phase control and precise time alignment. The M16 supports both high- and low-level inputs, includes eight DSP-processed RCA preamp outputs for additional amplification or powered subwoofers, and can be configured via USB using MUSWAY’s DSP software.

Features

  • 16-Channel Class D Amplifier
  • Integrated 24-Channel DSP
  • Dynamic Headroom (DHR) Technology
  • 31-Band Parametric Equalizer & Advanced Crossover Controls
  • 8-Channel DSP-Processed RCA Preamp Outputs

Specifications

AMPLIFIER STAGE


THD, 1 kHz @ 4 Ω, 5 W

0.01 %

Bandwidth @ - 1 dB

10 Hz - 22 kHz

S/N ratio @ A weighted, 1 V, Max. Power

100 dB

Damping factor @ 1 kHz, 2 V/RMS, 4 Ω

> 75

Input Sensitivity


CH1 - CH12 (High Level)

3 - 24 V/RMS

CH13 - CH20 (High Level)

4 - 32 V/RMS

CH1 - CH6 (Low Level)

0.7 - 6 V/RMS

AUX L/R (Low Level)

1 - 8 V/RMS

Output Power @ 13.8 V


CH1 - CH12

12 x 50/85 Watts RMS @ 4/2 Ω

CH13 - CH16

4 x 125/215 Watts RMS @ 4/2 Ω

Output Power bridged @ 13.8 V


CH1 - CH12

6 x 170 Watts RMS @ 4 Ω

CH13 - CH16

2 x 430 Watts RMS @ 4 Ω

Output Power DHR* @ 13.8 V


CH1 - CH12 per channel up to

65/110 Watts RMS @ 4/2 Ω

CH13 - CH16 per channel up to

130/240 Watts RMS @ 4/2 Ω

Output Power @ 14.4 V


CH1 - CH12

12 x 60/95 Watts RMS @ 4/2 Ω

CH13 - CH16

4 x 135/235 Watts RMS @ 4/2 Ω

Output Power bridged @ 14.4 V


CH1 - CH12

6 x 190 Watt RMS @ 4 Ω

CH13 - CH16

2 x 470 Watts RMS @ 4 Ω

Output Power DHR* @ 14.4 V


CH1 - CH12 per channel up to

70/120 Watts RMS @ 4/2 Ω

CH13 - CH16 per channel up to

145/265 Watts RMS @ 4/2 Ω

POWER SUPPLY


Operating Voltage

8 - 17 V

Idle Current

2.5 A

Switched Off

< 0,1 mA

Remote IN

7.5 - 17 V (1 mA)

Remote OUT

7.5 - 17 V (300 mA)

Fuses (inside on PCB)

4 x 35 A

SIGNAL OUTPUTS


RCA Preamplifier Outputs CH 17 - CH24

5 V/RMS

DIGITAL SIGNAL PROCESSOR (24 channels, 64 bit Clock speed: 295 MHz)


Crossovers

Fullrange / Highpass / Lowpass / Bandpass

Crossover Types

Bessel / Butterworth / Linkwitz

Slope

6/12/18/24/30/36/42/48 dB

Frequency Range

1 Hz Steps @ 20 Hz - 20 kHz

Phase Inversion

0° / 180°

Output Equalizer

31-Band Parametrical, ±15 dB

Time Alignment Distance

0 - 602 cm

Time Alignment Delay

0 - 17 ms

Time Alignment Steps

0.08 ms; 2.8 cm

Time Alignment Fine Set

0.02 ms; 0.7 cm

Presets

6

SIZE / WEIGHT


Dimensions without Mounting Plate

350 x 46 x 166 mm

Net Weight

3.1 kg


Scope of delivery

  • 1 x M16 DSP Amplifier
  • 1 x 1,5 m USB Cable
  • 1 x 20-pole Cable Adapter (High Level Inputs)
  • 1 x 24-pole Cable Adapter (High Level Inputs, REM)
  • 1 x 24-pole Cable Adapter (Speaker Outputs)
  • 1 x 8-pole Cable Adapter (Speaker Outputs)
  • 1 x 12-pole Cable Adapter (Low Level Inputs)
  • 1 x Mounting Plate incl. Screws
  • 1 x Owner’s Manual (English/German)
  • 4 x 35 A replacement fuse
  • 1 x 4 mm hex key

For more information, please visit the manufacturer's website.
