Musway M4 v4 4ch Amplifier 6ch DSP
Musway M4 v4 4ch Amplifier 6ch DSP
Musway M4 v4 4ch Amplifier 6ch DSP
Musway M4 v4 4ch Amplifier 6ch DSP

Musway M4 v4 4ch Amplifier 6ch DSP

$800.00
$800.00
Brand: Musway
SKU: MUS M4 V4
Availability: In Stock
4ch Class D Amplifier + 6ch DSP
4x 70 watts RMS @ 2Ω
4x 55 watts RMS @ 4Ω
Dimensions: 165 x 41 x 150mm

Purchase

If you are interested in buying this item please contact us via our contact page.

Contact Us
$15 Flat rate shipping*

Description
Description
x

Musway M4 v4 4ch Amplifier 6ch DSP 512k Bitrate

Featuring compact dimensions which are made possible by an elaborate 4-fold laminated board, which also effectively suppresses EMC interference due to the favorable topology - a must, especially for full-range Class D amplifiers.

The centerpiece is the state-of-the-art DSP chip ADAU1452 from Analog Devices, which was fine-tuned by the MUSWAY engineers and leaves no audiophile wishes unfulfilled. The amplifier finds its connection via a space-saving cable harness with ISO plugs, individual Plug+Play cable sets are also available. Useful additional features include soft-clipping to protect the electronics and speakers in 2 Ω operation and the newly developed high-level input with Error Protection System. When connected to an OEM factory radio the Error Protection System ensures that no functions are impaired or error messages are written into the vehicle memory.

Features

  • Intelligent High Level Input (Error Protection System)
  • Start-Stop ready, Auto Turn-On
  • Burr-Brown converters (PCM3168A) and Analog Devices DSP (ADAU1452)
  • 32bit, 295MIPS DSP technology, controllable via new V3 PC software or Tunest App
  • Signal-to-noise Ratio ≥90dB
  • Frequency Response 15 Hz – 22 kHz (-3dB)
  • THD ≤0,1% (1 kHz, 4Ω, 90% Power)
  • Controllable AUX input sensitivity, Clipping LEDs
  • Plug+Play with vehicle-specific cable sets

Specifications

Power output(RMS) @ 14.4 VDC, 1% THD

4CH @ 4 Ω：55 W x 4

4CH @ 2 Ω：70 W x4

2CH - (bridged 1/2; 3/4) @ 4 Ω: 145 W x 2


6 x High Level Input,10-30V RMS


2 x AUX/RCA Input, 1-8V RMS


4 x Loudspeaker Output amplified


6 x Pre-Amplifier Output/RCA (configurable via DSP)

Dimensions

165 x 41 x 150 mm



For more information, please visit the manufacturer's website.
