10" Slim reference Subwoofer dual 2Ω voice coils
Power Handling: 500 watts RMS
Peak Power: 1000 watts
Mounting Depth: 74.1mm
Power Handling: 500 watts RMS
Peak Power: 1000 watts
Mounting Depth: 74.1mm
Purchase
If you are interested in buying this item please contact us via our contact page.
$15 Flat rate shipping*
Description
xMusway MWF1022SQ 10 Inch Slim Reference Subwoofer Dual 2 Ω Voicecoil
There are flat subwoofers. And then there's the MWF1022SQ. With this exceptional subwoofer, MUSWAY redefines what's possible in the realm of ultra-flat, high-performance subwoofers. State-of-the-art design, uncompromising material selection, and one clear goal: maximum bass performance with minimal space requirements. With a mounting depth of just 7.4 cm, the MWF1022SQ opens up entirely new possibilities in modern vehicles where every centimeter counts. Whether in enclosures, spare tire wells, or discreetly integrated into side panels, the MWF1022SQ enables virtually invisible installations even in the most challenging spaces.
Despite its extremely flat design, the MWF1022SQ offers an impressive Xmax of ± 20 mm. This is an exceptional value in this segment – and clearly demonstrates that no compromises have been made. The subwoofer is consistently designed for dynamic, high-output, and precise bass reproduction. The MWF1022SQ is a pure chassis subwoofer designed for installation in a separate enclosure. It truly shines in small, sealed enclosures, where it impresses with high impulse response, clean control, and excellent precision – slim in design, big on sound.
From the very first touch, the MWF1022SQ underscores its premium aspirations: A robust protective grille and a precision-machined aluminum mounting ring are included as standard. Both components enhance mechanical stability, ensure torsionally rigid integration, and guarantee a permanently secure installation – even under high mechanical stress. This isn't just an add-on; it's a clear statement of quality. The highly rigid basket structure minimizes resonance and warping – even at extreme excursions. The open, flow-optimized design ensures efficient ventilation of the driver system.
Specifications
|
Power |
500 Watts RMS 1000 Watts Peak |
|
Impedance |
2 + 2 Ohms |
|
Voice Coil |
38.6 mm |
|
Magnet |
2.154 kg |
|
Resonance Frequency |
Fs 34 Hz |
|
Total Q-Factor |
Qts 0.6 |
|
Equivalent Air Volume |
VAS 18.6 L |
|
Xmax |
+/- 20 mm |
|
Efficiency 1W/1m |
SPL 89 dB/2.83 V/1m |
|
Installation Depth |
74.1 mm |
|
Installation Diameter |
231.5 mm |
|
Recommended Enclosure |
Sealed Box Sealed Volume 14 - 25 L -3 dB Rolloff (F3) 40 Hz |
For more information, please visit the manufacturer's website.
